LN KEY
Product Not Available
For Inquiry
Delivery Options Available
- 2-3 Days Normal Delivery
- 24 Hours Express Delivery
Warranty
NOEasy Return
Available, T&C ApplyDescription
Allen Key (Also known as Hex Key, Hexagon Key, Socket Key, LN Key), sizes and its dimensions can be very handy while designing and selecting fasteners for your application. These dimensions of allen keys can be used to check the accessibility of your bolts were space is limited.
Screw Size | Allen Key Size, s | A | B |
M3 | 2.5 | 56 | 18 |
M4 | 3 | 63 | 20 |
M5 | 4 | 70 | 25 |
M6 | 5 | 80 | 28 |
M8 | 6 | 90 | 32 |
M10 | 8 | 100 | 36 |
M12 | 10 | 112 | 40 |
M14 | 12 | 125 | 45 |
M16 | 14 | 140 | 56 |
M18 | 14 | 140 | 56 |
M20 | 17 | 160 | 63 |
M22 | 17 | 160 | 63 |
M24 | 19 | 180 | 70 |
