Petzl Reeve Carriage Pulley for Rescue on a Tensioned Highline
Rs. 38820For Inquiry
Product Specification
- Color(s) : Yellow
- Weight : 650 g
- Material(s) : Aluminum, stainless steel, nylon
- Min. rope diameter : 7 mm
- Max. rope diameter : 13 mm
- Sheave type : Sealed Ball Bearings
- Sheave diameter : 38 mm
- Working Load Limit : 4 x 2 kN = 8 kN
- Breaking strength : 36 kN
- Efficiency : 95 %
- Guarantee : 3 years
- Certification(s) : CE EN 12278, NFPA 2500 General Use, UKCA, XF 494: FZL-H-T 9.5/13
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
TC001Warranty
NOEasy Return
Available, T&C ApplyDescription
- Operations and efficiency are optimized:
- Triple-action opening of moving side plates, possible even with gloves
- Red indicators provide a visual warning when the side plates are not correctly locked
-Two large-diameter sheaves mounted on sealed ball bearings for excellent efficiency
- Possible to rig the system before installing it on the main line - Multiple configurations and connections are possible:
- System can be made redundant by placing two REEVE pulleys side by side (if distance between ropes permits), or by connecting a pulley to the upper connection hole for ropes at a further distance
- Pulley can be used in a haul system
- Hole design allows ropes or slings to be threaded for direct connection
- 19 mm holes allow locking sleeves of most carabiners to pass through
- The odd number of attachment holes enables the system to be centered and balanced
- Up to three people can be connected at the same time
