Rishabh 1P E Series Power Supply Rish Flex 1512A

Write a Review

Description

1. Input data:
1. AC input voltage range: 85 VAC ... 264 VAC
2. DC input voltage range: 120 VDC ... 370 VDC
3. Nominal Input Voltage: 115 VAC / 230 VAC (165 VDC / 325 VDC)
4. Input current: 18 A typical
5. AC frequency range: 45 Hz ... 65 Hz
6. Input current: 0.4 A (115 VAC), 0.3 A (230 VAC)
7. Internal fuse: T2 A
8. External fuse (recommended): 10 A (MCB curve B)
2. Output data:
1. Nominal output voltage: 12 VDC ± 3%
2. Rated current:
   1. 1.25 A @ 50 °C
   2. 0.94 A @ 60 °C
   3. 0.625 A @ 70 °C
3. Amplification Current @ 60 °C: 1.25 A (For 3 min)
4. Standby time: ≥ 50 milliseconds (230 VAC), 15 milliseconds (115 VAC)
5. Regulation current: <± 0.5%
6. Load regulation: <± 0.5% (variable load, static 10% ... 90%)
7. Overload: 105 ... 180% of rated output power
8. Maximum load power consumption: 2.24 W
9. Efficiency: > 87%
10. Residual ripple*: 120 mVpp
11. Short circuit protection: Yes
12. Overload protection: Yes
13. Output overvoltage protection: Yes, 24 VDC Typ.
14. Parallel connection: No
15. Serial connection: Yes
16. Turn on delay: 1 second
17. Increment time: 100 milliseconds
18. Reverse Resistance: 16 VDC . Max
3. General specifications:
1. Insulation voltage input/output: 3000 V AC
2. Degree of protection: IP20 (EN/IEC 60529)
3. Protection level: II
4. Mean time between two failures: > 5,00,000 hours according to IEC 61709 (SN29500)
5. Coating type: plastic coating
6. Coating material: PC Lexan 940
7. Dimensions: 18 mm / 90 mm / 62 mm (R/C/D)
8. Weight: approx. 0.2 Kg
9. Terminal block connection: 2.5 mm² . type screw
4. Environmental conditions:
1. Ambient temperature (operating): -30 °C ... +70 °C
2. Ambient temperature (storage): -40 °C ... +85 °C
3. Humidity at 25°C: 95% (non-condensing)
4. Level of environmental pollution: 2 (according to EN 50178)
5. Climate class: 3K3 (according to EN 60721)
5. Standard
1. Electrical safety:
1. Equipment assembly:
1. IEC/EN 60950 (VDE 0805)
2. EN 50178 (VDE 0160)
2. Install according to: IEC/EN 60950
3. Input/output separation: EN 60950-1 (SELV), EN 60204-1 (PELV) double or reinforced insulation
2. EMC standard exemption:
1. EN 61000-4-2
2. EN 61000-4-3
3. EN 61000-4-4
4. EN 61000-4-5
3. EMC emission standards:
1. EN 61000-6-4
2. EN 61000-3-2
