Chint 18 amp Contractor
Rs. 1965For Inquiry
Product Specification
- Model: 1810 (18 Amps / 1 Normally Open Aux)
- Number of Main Poles: 3 NO (Three-Phase)
- Rated Operational Current (\(I_{e}\)): 18 A (under AC-3 load conditions)
- Conventional Thermal Current (\(I_{th}\)): 25 A to 32 A max
- Controlled Motor Power (\(P_{e}\)): 7.5 kW at 380V/400V AC
- Rated Insulation Voltage (\(U_{i}\)): 660 V to 690 V AC
- Standard Control Coil Voltages: 24V, 110V, 220V/230V, or 380V AC (50/60Hz)
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
HT002Warranty
NOEasy Return
Available, T&C ApplyDescription
- Compact Design: Space-saving structural footprint ideal for crowded electrical control panels and distribution boards.
- Dual Mounting Options: Integrates natively onto a standard 35mm DIN rail or can be securely screw-mounted directly to a backplate
- Modular Auxiliary Extension: The front-facing mechanical actuator accepts top-mounted auxiliary block add-ons if you need more NO or NC diagnostic signals.
- High Electrical Durability: Built to handle up to 1,000,000 switching operations under full load conditions
