Cruxweld 415V Welding Machine ARC600i
Rs. 137295Product Specification
- Input voltage: AC415±15%
- Phase No: 3
- Frequency: 50/60Hz
- Max input KVA@100% duty cycle: 20.5KVA
- Open circuit voltage: 85V
- Welding current range: 20-600Amps
- Rated input current: 52Amps
- Welding current @60% duty cycle: 600Amps
- Welding current @100% duty cycle: 465Amps
- Efficiency: 87%
- Degree of protection Class: IP23S
- Insulation Class: H
- Hot start & arc force: Adjustable from front panel
- Cooling Type: Forced Air
- Dimensions (LxWxH) mm:670x320x640
Delivery Options Available
- 2-3 Days Normal Delivery
- 24 Hours Express Delivery
Sold By
PT030Warranty
NOEasy Return
Available, T&C Apply
5% OFF
Min.spend NRs. 3500
Description
- Three phase inverter based, high efficiency and high power factor heavy duty DC rectifier
- Suitable for all kind of acidic, basic, stainless steel, cellulosic and low hydrogen alloy electrodes in all welding positions
- High ambient temperature resistance up to 550C-ideal for Indian atmospheric conditions
Works with 100 meters long output cable without current drop - Suitable for all types of gauging application
- Can be powered from the mains or generator power supply, even via extra long supply cables, thus ideal for
on-site use - IP 23S rating designed & approved for outdoor use
- Safe to use in damp or humid welding environments due to reduced Open Circuit Voltage
- Equipped with VRD system for your safety
- High reliability and low serviceability to be absolutely sure the product will do the job
- Adjustable hot-start and arc force for accurate weld
