Electric Chain Hoist 3TX6M
Rs. 151395For Inquiry
Product Specification
- Lifting Capacity: 3 Tons (3,000 kg / ~6,600 lbs).
- Standard Lift Height: 6 Meters (approx. 20 feet).
- Motor Power: Typically 3.0 kW (industrial 3-phase).
- Lifting Speed:
Single-fall chain: ~5.4 to 6.6 m/min.
Dual-fall chain: ~4.4 m/min (more common for 3T models for increased mechanical advantage). - Chain Diameter: Usually 11.2 mm (Grade 80 or G100 alloy steel).
- Power Supply: Standard industrial 3-Phase
- Control Voltage: 24V, 36V, or 48V (low voltage for operator safety).
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
PT033Warranty
NOEasy Return
Available, T&C Apply
Description
- Shell: Light aluminum alloy body with cooling fins for rapid heat dissipation.
- Braking: Dual system featuring an electromagnetic brake for instant stopping upon power cut-off.
- Limit Switches: Top and bottom limit switches to prevent the chain from running out or over-traveling.
- Chain Container: Usually includes a high-durability canvas or plastic bag to prevent chain tangles.
- Protection Rating: Typically IP54 for the hoist body and IP65 for the pendant control (splash-proof and dust-protected).
