Phoenix Timer Relay TR-ES-MUL-24/240-10H 2907322
Product Not Available
For Inquiry
Product Specification
- Product type: Timer relay
- Mechanical service life: approx. 1x 106 switching cycles
- Service life electrical: approx. 1x 105 cycles
- Nominal frequency: 48 Hz ... 63 Hz
- Nominal power consumption: 8 VA (1 W, 230 V AC), 0.4 W (at 24 V DC)
- Test voltage relay winding/relay contact: 1.6 kV
- Rated insulation voltage: 300 V
- Rated surge voltage: 2500 V
- Connection name: Non-floating, terminals A1-B1
- Control pulse length: ≥ 25 ms (DC), ≥ 50 ms (with AC)
Delivery Options Available
- 2-3 Days Normal Delivery
- 24 Hours Express Delivery
Sold By
HT015Warranty
YESEasy Return
Available, T&C ApplyDescription
- Multi-functional timer relay with 7 functions and an adjustable time range (50 ms - 10 h), supply voltage: 24 V DC … 48 V DC/24 V DC … 240 V AC, 1 changeover contact
