Tiger Heavy Duty Manual Chain Block 3TX3M
Rs. 19520For Inquiry
Product Specification
- Lifting Capacity: 3 Tons (3,000 kg / 6,613 lbs)
- Standard Lift Height: 3 Meters (~10 ft)
- Load Chain: 2 strands (double fall) of G80 or G100 alloy steel
- Chain Diameter: Typically 7.1 mm or 8 mm
- Effort Required to Lift Max Load: Approximately 332 N to 343 N (requires about 34–35 kg of manual pull force)
- Test Load: Proof tested to 1.5 times the rated capacity (4.5 tons)
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
PT033Warranty
NOEasy Return
Available, T&C ApplyDescription
- Safety Braking: Equipped with a dual-pawl Weston-style brake system for instant, secure load holding.
- Durable Construction: Rugged steel body with a powder-coated finish for corrosion resistance in harsh environments.
- Forged Hooks: 360° swivel hooks made of high-tensile steel, designed to stretch slowly if overloaded rather than snap.
- Efficiency: Precision-machined triple spur gears and sealed bearings ensure smooth operation with minimal manual effort.
- Temperature Range: Certified for operation in extreme temperatures, typically ranging from -40°C to +80°C
