Tiger Heavy Duty Manual Chain Block 2TX6M
Rs. 19785For Inquiry
Product Specification
- Lifting Capacity: 2.0 Metric Tons (2,000 kg)
- Lifting Height (HOL): 6.0 Meters (approx. 20 ft)
- Number of Chain Falls: 1 (Single Fall)
- Load Chain Diameter: 8.0 mm (Grade 80/100 Alloy Steel)
- Hand Pull Force:~314 N to 360 N (at full load)
- Standard Testing: Proof tested to 1.5 times rated capacity (3.0t)
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
PT033Warranty
NOEasy Return
Available, T&C ApplyDescription
- Single Fall Design: Unlike standard 2-ton blocks that use two chains, the Tiger VD Type uses a single 8mm chain, preventing twisting and significantly reducing the overall unit weight for better portability.
- Patented Quad Cam Pawl System: Ensures a fail-safe braking mechanism; if one pawl spring fails, the others remain engaged to prevent the load from dropping.
- Extreme Environment Ready: Certified for operation in temperatures ranging from -40°C to +80°C, making it suitable for offshore and mining industries.
- Enhanced Brake Protection: Features double-cover protection for the brake chamber, sealing out water, dust, and debris for reliable operation in harsh conditions.
Low Headroom: Engineered for tight spaces, with a compact hook-to-hook distance (typically 380mm – 420mm) when fully raised. - Light Load Safety: Guaranteed to hold loads as small as 2% of the rated capacity (40 kg), which is a critical safety feature many standard hoists lack
