Tiger Heavy Duty Manual Chain Block 5TX3M
Rs. 29470For Inquiry
Product Specification
- Lifting Capacity: 5 Tons (5,000 kg / 11,023 lbs)
- Standard Lift Height: 3 Meters (~10 ft)
- Load Chain Strands: 2 strands (double fall)
- Load Chain Diameter: 10 mm high-grade alloy steel (G80)
- Effort Required to Lift Max Load: Approximately 380 N to 420 N (requires about 38–42 kg of manual pull force)
- Running Test Load: Proof tested to 62.5 KN (approx. 1.25 to 1.5 times rated capacity)
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
PT033Warranty
NOEasy Return
Available, T&C ApplyDescription
- Braking System: Features an automatic double-pawl braking system for secure load holding and precise control during lowering.
- Heavy-Duty Hooks: Equipped with drop-forged, heat-treated 360° swivel hooks with safety latches. These are designed to deform slowly if overloaded to provide a visual warning.
- Durable Housing: A double-cover enclosure protects the internal brake chamber and gears from dust, water, and impact damage.
- Mechanical Efficiency: Uses precision-machined triple spur gears and a pinion shaft to minimize the manual effort required for heavy lifting.
- Compliance: Designed to meet international safety standards such as CE (2006/42/EC), ASME B30.16, and AS 1418.2
