Vedal HS-C Manual Chain Pulley Block 3TX6M
Rs. 15665For Inquiry
Product Specification
- Rated Capacity: 3 Tons (3,000 kg / 6,613 lbs)
- Standard Lift Height: 6 Meters (approx. 20 ft)
- Load Chain Strands: 2 (Double Fall)
- Load Chain Diameter: 7.1 mm or 8 mm (G80 Alloy Steel)
- Hand Pull Force: ~330 N – 350 N (approx. 34–36 kg effort required).
- Headroom (Hook-to-Hook): ~470 mm – 520 mm (minimum space when fully raised)
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
PT033Warranty
NOEasy Return
Available, T&C ApplyDescription
- Double-Fall Load Chain: Distributes the 3-ton weight across two strands of G80 alloy chain, reducing the mechanical stress on each link and improving safety.
- Advanced Braking: Equipped with a dual-pawl Weston-style brake that holds the 3,000 kg load instantly and securely at any height.
- Extended Reach Capability: Designed for high-lift industrial applications like bridge building, engine room maintenance, or high-bay warehouse installations.
- Forged Swivel Hooks: High-tensile steel hooks that rotate 360° to prevent the double-strand chain from twisting or tangling during the 6-meter travel.
- Precision Gears: Hardened steel spur gears and bearings provide smooth, reliable operation even under maximum load.
