5TX6M Electric Chain Hoist
Rs. 271875For Inquiry
Product Specification
- Lifting Capacity 5.0 Tons (5,000 kg / 11,000 lbs)
- Lift Height 6 Meters (approx. 20 feet)
- Lifting Speed ~2.7 m/min
- Motor Power ~3.0 kW – 4.5 kW
- Power Supply 3-Phase (typically 380V/440V, 50/60Hz)
- Load Chain Grade 80 or G100 Alloy Steel (~11.2 mm diameter)
- Chain Falls 2 Falls (The chain loops through a bottom hook block)
- Trolley Travel Speed ~11 – 21 m/min (Motorized movement)
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
PT033Warranty
NOEasy Return
Available, T&C Apply
Description
- Running Type (01-01): Includes an Electric Trolley, allowing the hoist to move horizontally along an I-beam or H-beam via the pendant control.
- Dual-Brake System: Combines a magnetic brake and a mechanical brake for redundant safety; the hoist will hold the load even if power is lost.
- Heavy-Duty Housing: Features a die-cast aluminum alloy body with cooling fins for high heat dissipation during intensive use.
- Reverse Phase Protection: A safety relay that prevents the motor from running if the power phases are incorrectly wired.
- Limit Switches: Integrated upper and lower limit switches to automatically stop the motor at the ends of the chain's travel.
- Control Pendant: 4-button waterproof pendant (Up/Down/Left/Right) with an Emergency Stop button.
