Tiger Heavy Duty Manual Chain Block 5TX10M
Rs. 45600For Inquiry
Product Specification
- Lifting Capacity: 5 Tons (5000 kg/11023 lbs)
- Lifting Height: 10 Meters
- Load Chain: 2 strands (double fall) of 10 mm Grade 80 (G80) alloy steel.
- Effort to Lift Max Load: Approximately 415 N to 440 N (requires roughly 42–45 kg of manual pull force).
- Headroom: Approximately 640 mm (minimum distance between top and bottom hooks).
Delivery Options Available
- 1 -2 Days Normal Delivery
- 24hr Hours Express Delivery
Sold By
PT033Warranty
NOEasy Return
Available, T&C ApplyDescription
- High-Lift Safety: Features a dual-pawl Weston-style brake for constant, fail-safe load control over long vertical distances.
- Internal Protection: A double-cover enclosure protects the braking mechanism and gears from debris, which is critical for long-reach outdoor or construction use.
- Forged Hooks: 360° swivel hooks with safety latches; designed to yield (stretch) slowly if overloaded, providing a clear visual warning.
- Precision Gearing: Heat-treated triple spur gears ensure maximum mechanical advantage, reducing operator fatigue during long lifts.
